Description
108-034-01 Roll Ring Tensioner is a high quality, maintenance free, and self adjusting chain tensioner. The chain tensioner installs in seconds and even works in reversing applications. The 108-034-01 size tensioner works with sizes 08B and #40 chain, and features 34-teeth. It’s manufactured out of a specially formulated polymer that has a resistance to ultra violet rays, radiation, temperatures, a wide range of chemicals, abrasion, and doesn’t change chemically under vacuum conditions.
Dimensions:
- Tensioner Size: RR500-34
- Chain Size: 08B, #40
- Pitch: 0.500″
- Article #: 108-034-01
- Teeth: 34
- d0: 5.41″
- di: 4.54″
- S: 1.18″
- A: 6.50″
- D=d0-s: 4.23″
- Expansion Force: 4.84 LBS
- Maximum Chain Speed: 28.9 ft/sec
Static and Dynamic Tension
With regard to the chain speed, all roll ring tensioners can be used up to the maximum chain speed specified by the manufacture specified for manual lubrication and for drip lubrication. The laterally open teeth on the toothed cog of the chain tensioner dampen the roll impact in the chain intake. For additional information or to get a quote please contact us and we will be happy to assist you.
Phone: (407) 347-3519
Email: sales@usarollerchain.com
