Description
Style 114 flared trough end for 20″ screw conveyor with 3-7/16″ Ball bearing is designed with a top flange to support the cover and a bottom flange which serves as feet for the screw conveyor. Our flared trough ends are manufactured from high-quality heavy-gauge steel for superior strength and holding capacity over time. 114 flared trough ends are designed to specifically fit a flared trough. Typically, 114 trough ends are fitted with a transmission ball bearing but additional bearing types are available such as bronze, Arguto wood, nylon, bronze oilite, and it can be fitted with a Chevron or Hammond end thrust bearing as well. For more information or to get a quote on #114 flared trough end for 20″ screw conveyor with 3-7/16″ Ball bearing contact us and our customer service team will be happy to assist you!
114 Flared Trough End For 20″ Conveyor With 3-7/16″ Bearing Dimensions
- Part #: 230-0986
- Diameter of Conveyor: 20″
- Bearing Bore: 3-7/16″
- Dimension (A): 39-1/2″
- Dimension (B): 7-3/8″
- Dimension (C): 2-1/2″
- Dimension (D): 13-1/2″
- Dimension (E): 15″
- Dimension (F): 2-1/4″
- Dimension (G): 3-3/4″
- Dimension (H): 3/4″
- Dimension (J): 19-1/4″
- Dimension (K): 3/8″
- Weight With Bearing: 197 LBS
