Description
HCFS214-43 bearing is a 2-11/16″ bore four-bolt normal-duty flange bearing that utilizes an eccentric locking device to secure to a 2-11/16″ shaft. HCFS214-43 flange bearings are designed for circumstances where the bearing is mounted to a surface perpendicular to the shaft axis and poses great stability and rigidity due to the four mounting positions. Our superior HCFS214-43 bearing with a 2-11/16″ bore is equipped with a premium C3 precision insert bearing housed within a high-strength solid-base cast-iron housing. Additionally, our HCFS214-43 bearing has added features that improve the overall life and performance of the unit, such as; a steel retainer, wide inner-ring, anti-rotation device, and relubricating capabilities. HCFS214-43 bearings are commonly used in applications such as; construction equipment, agricultural equipment, forestry, aggregate, conveyor systems, and many more. Our HCFS214-43 bearing is dimensionally made to industry standards, meaning it interchanges with just about any brand out there. Contact our customer support team for further information or to get a quote on our HCFS214-43 bearings, and we will be happy to assist you!
HCFS214-43 Bearing Dimensions
- Part #: HCFS 214-43
- Shaft Diameter (d): 2-11/16″
- Dimension (A): 7.38″
- Dimension (E): 5.875″
- Dimension (I): 1.50″
- Dimension (G): 0.91″
- Dimension (L): 2.38″
- Dimension (S): 0.71″
- Dimension (Z): 3.50″
- Dimension (Bi): 3.3740″
- Dimension (N): 1.3425″
- Dimension (M): 1.3425″
- Bolt Used: 5/8
- Dynamic Load Rating (LBS): 13,981
- Static Load Rating (LBS): 9,869
- Bearing Insert: HC 214-43
- Housing Number: FS 214
- Weight (LBS): 13.6
