Description
SBPF209-27G stamped steel bearing is a 4-bolt flange bearing designed for light-duty industrial and agricultural applications. The superior quality greasable stamped steel housing encases a performance C3 precision 1-9/16″ insert bearing that utilizes set screws for securing onto a shaft. SBPF209-27G bearings are more economical than their cast counterparts but offer excellent performance in bearing applications; the four-bolt flange stamped steel housing allows for great mounting when the shaft is positioned perpendicular to the bearing. Utilizing four mounting holes, the SBPF209-27G 1-9/16″ bearing has incredible holding power and stability. Additionally, our SBPF209-27G stamped steel bearing features a zinc plated housing for added protection against the elements in corrosive or outdoor applications, and is equipped with a grease zerk for re-lubing capabilities. For more information or to get a quote on our SBPF209-27G bearing, contact our customer support team, and we will be happy to assist you!
SBPF209-27G Bearing Dimensions
- Part #: SBPF209-27G
- Bearing ID: 1-9/16″
- Dimension (a): 5-55/64″
- Dimension (e): 4-49/64″
- Dimension (g): 9/64″
- Dimension (c): 7/8″
- Dimension (s): 1/2″
- Dimension (f): 3-13/16″
- Dimension (Bi): 1.625″
- Dimension (n): 0.375″
- Bolt Size: 1/2″
- Number of Bolt Holes: 4
- Insert Bearing #: SB209-27
- Housing #: PF209G
- Weight: 3.05 LBS
