Description
This E10B14 sprocket with a stock bore is a metric roller chain sprocket manufactured under ISO and British Standard 228/11. Our E10B14 sprockets are made with reliability and performance in mind, so we use high-quality carbon steel (CS) and have the sprocket precision cut to ensure maximum performance and wear life. Besides the stock bore we also can supply these sprockets with a specific plain or finished (has key-way and set screws) bore size. We also offer upgrades on our triple E10B14 sprockets such as black-oxide coatings and heat-treated hardened teeth, though we often have these specific sprockets with those features already added right off the shelf. Besides the 14 tooth sprocket, we also stock a high-quality 10B-3 roller chain and a wide array of roller chain accessories. For more information or to get a quote on E10B14 sprockets, please contact us and one of our sales team members will be happy to assist you.
E10B14 Sprocket Dimensions
- Sprocket Size: E10B14
- Tooth Count: 14
- Pitch Diameter: 71.34mm
- Stock Bore: 16mm
- Maximum Recommended Bore: 35mm
- Hub Diameter (H): 53mm
- Length Thru Bore (L): 55mm
- Sprocket Weight: 1.23 kg
