Description
UCWF201-8 bearing is a 1/2″ bore four-bolt normal-duty flange bearing that utilizes set screws to secure to a 1/2″ shaft. UCWF201-8 flange bearings are designed for circumstances where the bearing is mounted to a surface perpendicular to the shaft axis and poses great stability and rigidity due to the four mounting positions. Our superior UCWF201-8 bearing with a 1/2″ bore is equipped with a premium C3 precision insert bearing housed within a high-strength solid-base cast-iron housing. Additionally, our UCWF201-8 bearing has added features that improve the overall life and performance of the unit, such as; a steel retainer, wide inner-ring, anti-rotation device, relubricating capabilities, and strategically placed set-screws. UCWF201-8 bearings are commonly used in applications such as; construction equipment, agricultural equipment, forestry, aggregate, conveyor systems, and many more. Our UCWF201-8 bearing is dimensionally made to industry standards, meaning it interchanges with just about any brand out there. Contact our customer support team for further information or to get a quote on our UCWF201-8 bearings, and we will be happy to assist you!
UCWF201-8 Bearing Dimensions
- Part #: UCWF 201-8
- Shaft Diameter (d): 1/2″
- Dimension (A): 3.00″
- Dimension (E): 2.13″
- Dimension (I): 0.59″
- Dimension (G): 0.44″
- Dimension (L): 1.00″
- Dimension (S): 0.44″
- Dimension (Z): 1.22″
- Dimension (Bi): 1.0787″
- Dimension (N): 0.3937″
- Dimension (M): 0.6260″
- Bolt Used: 3/8
- Dynamic Load Rating (LBS): 2,147
- Static Load Rating (LBS): 1,075
- Bearing Insert: UCW 201-8
- Housing Number: WF 203
- Weight (LBS): 1.3
